1、 Length of kitchen smoke exhaust pipe

厨房蜜桃91在线视频蜜桃APP下载网站水平段不宜过长一般远水平距离不应超过15m，坡度少应为2%。水平端有柔性接头，便于清理油脂。根据规范，排气速度少为10m/s，并且需要在与排气罩相连的支管中提供空气，以防止油因风速过低而粘附在烟囱上。

The horizontal section of kitchen smoke exhaust pipe should not be too long. Generally, the distance to the far horizontal should not exceed 15m, and the slope should be at least 2%. The horizontal end has a flexible joint to facilitate grease cleaning. According to the specification, the exhaust speed shall be at least 10m / s, and air shall be provided in the branch pipe connected to the exhaust hood to prevent oil from adhering to the chimney due to low wind speed.

二、厨房蜜桃91在线视频蜜桃APP下载网站设计安装的合理性

2、 Rationality of design and installation of kitchen smoke exhaust pipe

工程经验表明，主蜜桃91在线视频道风速不能超过15m/s。否则，经过一段时间的运行(如一年后)，蜜桃91在线视频系统很容易变钝。油烟净化器在运行中，多数情况下是因为排气管通风面积不够，管内气体流速在15m/s以上。

Engineering experience shows that the wind speed of the main exhaust flue shall not exceed 15m / s. Otherwise, after a period of operation (such as one year), the smoke exhaust system is easy to become dull. During the operation of the oil fume purifier, in most cases, the ventilation area of the exhaust pipe is not enough, and the gas flow rate in the pipe is more than 15m / s.

三、蜜桃91在线视频管不畅通的原因

3、 Reasons for blocked smoke exhaust pipe

1、由于蜜桃91在线视频管要穿过建筑梁，蜜桃APP下载网站的通风截面积变小，截面阻力变大，从而阻碍气流。

1. As the smoke exhaust pipe passes through the building beam, the ventilation cross-sectional area of the pipe becomes smaller and the cross-sectional resistance becomes larger, thus hindering the air flow.

2、蜜桃91在线视频管穿过建筑物横梁或避开其他设备蜜桃APP下载网站时，蜜桃91在线视频管的横截面低于整个蜜桃91在线视频管的平面。使用一段时间后，油水混合物会在排气管下部积聚，直接影响排气的顺畅性。

2. When the smoke exhaust pipe passes through the building beam or avoids other equipment pipes, the cross section of the smoke exhaust pipe is lower than the plane of the whole smoke exhaust pipe. After using for a period of time, the oil-water mixture will accumulate at the lower part of the exhaust pipe, which will directly affect the smoothness of exhaust.

3、不同楼层厨房油烟通过同一总管排出，靠近出风口的楼层厨房蜜桃91在线视频效果更好，而较低楼层厨房则不顺畅。

3. The oil fume of kitchens on different floors is discharged through the same main pipe. The smoke exhaust effect of kitchens on floors close to the air outlet is better, while the kitchens on lower floors are not smooth.
